The Digi-Mic Adapter is an easy to use optical component that allows one to conveniently attach any Digital Camera with the lens filter thread to a conventional or a stereo microscope. Just thread the Digi-Mic into a camera lens filter opening and insert the other end of the adapter into the microscope tube.


The main advantage  of the Digi-Mic Adapter is its increased field of View ( FOV)




Conventional Adapter FOV


Thanks to an improved optical design, the adapter's FOV is 14% LARGER than any other adapter on the market.



Digi-Mic Adapter FOV









FITS standard DIN 23 mm ID microscope tube
(Optiosnsal Adapter Ring for 30 mm ID Stereo tube)
37 mm male lens thread (Sony Digital Camera)
STEP-UP LOW PROFILE RINGS for other cameras( MALE threads: 41, 43, 46, 49, 52, 58 mm )
37 mm female thread

DMA-1 is an adapter designed for Nikon Cool-Pix 950 (and up) digital cameras with28 mm lens filter thread

We also design and manufacture custom optical adapters, imaging components and systems for digital and video cameras for medical, industrial and laboratory applications. For more information Please Feel free to contact us by email or write to us at :

OMEX TECHNOLOGIES INC.
3665 Woodhead Dr., Northbrook, IL 60062
Phone: 847-564-0206, FAX: 847-564-0306s
